Main Information :
| Shell style | Fixed receptacle |
| Internal components | 5 Pins |
| Sheating material | Brass shell and collet nut , nickel plated. Brass latch sleeve and mid pieces |
| Conductor Structure | Brass gold plated |
| Insulation | Peek |
| Conductor diameter | 1.3 mm |
| Maximum contact resistance | 3.6 mOhm |
| Rated current | 14 A |
| Test voltage ( Contact - Shell ) | 2.3 KV ( DC ) |
| Adapter cable | 1.00-12.60mm |
Description :
Push-Pull Self-locking Connector Model: 2TLGGD05CLL
Push-Pull Self-locking Fixed Receptacle Size 2T , 5 Socket Contacts, Solder , 1.00-12.60mm Collet – Cross Reference/Equivalent: EGG.2T.305.CLL
Datasheet:
Delivery is prompt!
By 10-year industry experts!
Diverse payment methods available!
Unbeatable cost performance!
